1600 ; 2000 mm ; 2500 mm ; 3200 mm ; 4000 mm ; 6100 mm
40T ; 50T ; 70T ; 100T ; 160T ; 200T ; 250T
CybTouch 8G
Integrated quenching enhances durability, ensuring a longer lifespan for the precision press brake tooling. Offers both upper and lower dies in various lengths, providing flexibility in configuration to meet diverse processing needs
Download our brochures to explore all technical specifications, tonnage capacities, and the different variations of our press brake
| Feature | Specification |
|---|---|
| Screen | 7" color graphic screen with LED backlight |
| Resolution | 800 x 480 pixels (WVGA) |
| Work memory | SRAM |
| System memory | FLASH memory with firmware update via RFlink |
| Communication | Cybellec RFlink (radio frequency link) |
| Axes |
±10 VDC: control of AC/DC drives and motors 0–10 VDC: frequency converter for AC asynchronous motors SP-SN-HS: 2-speed mode SP-SN 0–10 VDC: 2 adjustable speeds |
| Units | Inch / mm conversion |
| Power supply |
Numerical control: stabilized +24 VDC (-15% / +20%), 6 W Digital inputs / outputs: stabilized +24 VDC (-15% / +20%) |
| Encoder inputs |
2 × 5 VDC or 12 VDC* or 24 VDC (*external power supply) Complementary signals are not required (recommended) |
| Encoder power supply | 5 VDC supplied by CybTouch, max. 250 mA per encoder |
| Digital inputs | 8, opto-isolated |
| Analog inputs | 2 × 0–10 VDC |
| Digital outputs |
12, opto-isolated and fuse-protected 24 VDC, max. 0.7 A Possibility to duplicate outputs to increase current |
| Analog outputs |
3 × ±10 VDC Impedance < 100 Ω, short-circuit protection Load ≥ 2 kΩ (max. 15 mA) |
| Reference voltage | 10 VDC (max. 20 mA) for external potentiometer (recommended value: 2 kΩ to 5 kΩ) |
| Operating conditions |
Minimum temperature: 5 °C, maximum: 45 °C Relative humidity: 10% to 85%, non-condensing |
| CE standards | IEC61131-2 |
| Available languages | English, French, German, Italian, Dutch, Spanish, Portuguese, Portuguese (Brazil), Czech, Turkish, Chinese, Taiwanese, Polish, Russian |
