JY21 Series Semi-Closed Type Fixed Table Press

DESCRIPTION

The JY21 Series Semi-Closed Type Fixed Table Press by Yadon is a high-performance hydraulic press designed for precision stamping, forming, and other industrial applications. This press features a semi-closed structure with a fixed table for enhanced stability and accuracy during operations. Ideal for applications requiring high force and durability, it provides superior performance in metalworking, automotive, and other manufacturing industries. The machine is built for efficiency, energy savings, and long-term reliability.

MAIN STRUCTURE FEATURES:

  • High precision, Reaches JIS1 standard;
  • Semi-closed structure and high-rigidity steel-welded frame;
  • Locking six side guide rail;
  • Dry pneumatic friction clutch
  • Safety double solenoid value
  • High-sensitive hydraulic overload protection;
  • Concentrated oil automatic lubrication system
  • Frequency control
  • Mulitifunctional high affinity electronic control system

OPTIONAL:

  • Optional components: output shaft, air cushion, slide block,etc

Tech specifications

Download BROCHURE AND TECH SHEET

Download BROCHURE AND TECH SHEET

SPECIFICATIONS

SPECIFICATIONS

Category

NOMINAL PRESSURE

The nominal pressure varies depending on the model: JY21-45: 450 KN // JY21-63: 630 KN// JY21-100: 1000 KN // JY21-160: 1600 KN // JY21-200: 2000 KN // JY21-250: 2500 KN //JY21-315: 3150 KN // JY21-400: 4000 KN

POWER OF THE MOTOR

The main motor power is as follows: JY21-45: 5.5 KW // JY21-63: 7.5 KW // JY21-100: 11 KW // JY21-160: 15 KW // JY21-200: 22 KW // JY21-250: 30 KW // JY21-315: 37 KW // JY21-400: 37 KW

MODELS

JY21-45 // JY21-63 // JY21-100 // JY21-160 // JY21-200 // JY21-250 // JY21-315 // JY21-400
